Industrial Accelerometers - VIB 6.1X

Reliable and precise measurement of machine vibration.

  • One sensor measures vibration acceleration, shock pulse (roller bearing condition) and cavitation in pumps.
  • Patented tandem-piezo technology eliminates the disadvantages of conventional sensor types.
  • Lossless signal transmission over long distances up to 1,000 meters with current line drive (CLD) signal amplification.
  • Various mounting types.​


​Mini Accelerometers - VIB 6.20x

  • Types VIB 6.202, VIB 6.203
  • Compact design
  • Space-saving cable routing
  • Economically priced
  • Tandem-piezo measuring element
  • Current line drive (CLD) signal amplification
  • Mounting options: bolted, glued, magnetic
  • Vibration acceleration, shock pulse (roller bearing condition), cavitation in pumps
  • Intrinsically safe versions available.​


VIBCODE Transducer

The intelligent sensor knows at all times where to measure and which measurement is the right one.

  • Easy data collection
  • Coded measurement locations
  • Stable connection via bayonet mount
  • Reproducible results
  • Tandem-piezo measuring element
  • Current line drive (CLD) signal amplification
  • Vibration acceleration, shock pulse (roller bearing condition), cavitation in pumps
  • Compatible with VIBROTIP, VIBSCANNER, VIBXPERT
  • Measures signals on low-speed machines (>2 Hz)
  • Intrinsic safety (option)​


Laser trigger / RPM sensor

  • Type VIB 6.631
  • Connects to PRÜFTECHNIK data collectors
  • Laser optical measurement
  • Easy mounting and adjustment
  • Large RPM measurement range
  • Stable stands (accessory)
  • EX version available​
